| Power Model | RG-PA600I-P-F | RG-PD600I-P-F | |
|---|---|---|---|
| Maximum input voltage | AC input: 90 V AC to 290V AC; 47 to 63 Hz HVDC input: 192 V DC to 290V DC DC Input: -38 V DC to -75 V DC |
AC input: 90 V AC to 290V AC; 47 to 63 Hz HVDC input: 192 V DC to 290V DC DC Input: -38 V DC to -75 V DC |
|
| Maximum input current | AC input: 8A HVDC input: 4A |
20 A | |
| Input leakage current | ≤1.75 mA | ||
| Output Specifications | |||
| Output voltage | 56V | 56 V | |
| Maximum output current | 10.72 A | 10.72 A | |
| Maximum output power | 600 W | 600 W | |
| PoE output power | <600W | <600 W | |
| Dimensions and Weight | |||
| Dimensions (W x D x H) | 196 mm x 90 mm x 40mm (7.72 in. x 3.54 in. x 1.57 in.) |
196 mm x 90 mm x 40mm (7.72 in. x 3.54 in. x 1.57 in.) |
|
| Weight | Net weight: 0.9 kg (1.98 lbs.) | Net weight: 0.9 kg (1.98 lbs.) | |
| Environmental Specifications | |||
| Primary airflow | Rear-to-front: Air intake from the connector and air outlet from the front panel | Rear-to-front: Air intake from the connector and air outlet from the front panel | |
| Operating temperature | -10°C to +55°C (14°F to 131°F) | -10°C to +55°C (14°F to 131°F) | |
| Storage temperature | -40°C to +70°C (-40°F to +158°F) | -40°C to +70°C (-40°F to +158°F) | |
| Operating humidity | 5% to 95% (non-condensing) | 5% to 95% (non-condensing) | |
| Storage humidity | 5% to 95% (non-condensing) | 5% to 95% (non-condensing) | |
| Operating altitude | -500 m to +5,000 m (-1640.42 ft. to 16404.20 ft.) | -500 m to +5,000 m (-1640.42 ft. to 16404.20 ft.) | |
| Other Specifications | |||
| Power cord requirement | 10A power cord | DC power cord equal to or greater than 2.5 mm | |
| General Information | |
|---|---|
| Manufacturer: | Ruijie Networks |
| Manufacturer Part Number: | RG-PA600I-P-F |
| Barcode: | 6971693272781 |
| Packaging Details | |
| Weight: | 0.90 KGS |
| Width: | 9.00 (cm) |
| Height: | 4.00 (cm) |
| Depth: | 20.00 (cm) |
Ruijie PoE Power Adapter for RG-S5310 Series Network Switch, 370W is used with The RG-S5300-E series which are next-generation gigabit Ethernet switches launched by Ruijie according to its design philosophy of security, high efficiency, energy saving, and independent innovation. This series can provide full gigabit access and flexibly extensible 10G uplink data exchanges. With a new hardware architecture and Ruijie's latest RGOS12.X modular OS, the RG-S5300-E series are capable of providing more resource entries, faster hardware processing, and a better user experience.
FEATURES:
- AC Power
- Up to 370W
- 1+1 redundancy
